Onward 12 | Mannington Commercial

FIRST QUALITY

COLORS TEXTED RED ONLY

7.25' x 48' SPECIAL PLANK

SPECIAL - $2.49 / SQ. FT.

COLORS TEXTED RED ONLY

CAN BE LOOSE LAID

______________________________________

Specifications

Style Onward 12
Wood & Stone
Construction
Classification
Total Thickness
Overall Thickness
Wear Layer
Edge Treatment
Sizes
Colors
Packaging
Adhesive
Luxury Vinyl Tile
Non-ortho Phthalate
ASTM F1700 Class III, Type B
0.08” (2.0 mm)
12 mil (0.30 mm)
Enhanced Urethane
Unbeveled
6” x 36” (152 x 915 mm)
18” x 18” (457 x 457 mm)
Sizes are style dependent; refer to Product
Availability Chart
12 Wood, 4 Stone
6” x 36” - 40 pcs, 60 ft / ctn 44.7 lbs / ctn
18” x 18” - 16 pcs, 36 ft2  26.82 lbs / ctn
Porous & Non-porous Substrates:
V-88 Full Spread
MoistureLo􀁆 Full Spread, One Component
V-95 Full Spread, 2-part Epoxy
XpressStep for LVT & Sheet Vinyl Full Coverage Spray
N ote: Must use V-95, MoistureLoc, or XpressStep adhesive under heavy rolling load areas. This product is not recommended under
hospital beds. In more abusive conditions such as areas subject to dragging force, direct sunlight or where topical moisture would be a
concern, only V-95 or MoistureLoc should be used.
Installation Method All arrows in the same direction. Planks should have end joints offset by at least 6” and staggered
to create a random appearance. Tiles should be installed block or staggered; when quarter turned,
arrows should alternate.
