Mannington Biospec MD

Style BioSpec MD
Construction Homogeneous Sheet
Non-ortho phthalate construction
Classification ASTM F1913 Sheet Vinyl Floor Covering without Backing
Total Thickness 0.080” (2.03 mm)
Wear Layer Quantum Guard Elite®
Width 6’6” (2 m)
Colors 70
Pattern Repeat Random repeat, reverse sheet for seaming
Packaging 30-73 yd2 (25.1-61.04 m2)
(73 yd2 roll is approx. 100 lineal feet)
Weight 6.5 lbs/yd2 (2.948 kg/m2)
Adhesive Porous & Non-porous Substrates:
V-88 Full Spread, Transitional Pressure Sensitive, High Moisture
V-95 Full Spread, 2-part Epoxy
XpressStep for LVT & Sheet Vinyl Full Coverage Spray
Porous Substrates Only:
V-82 Full Spread, Acrylic Base
Note: Must use V-95 or XpressStep adhesive under hospital beds

and heavy rolling load areas. Use V-95 in Operating Rooms or
where higher risk of topical moisture would be a concern.
QuickStix® Available with QuickStix® pre-applied adhesive, reducing

 time and labor required to install the flooring.
QuickStix® floors can be used immediately after installation, even

in extreme moisture areas. Packaging
may differ for QuickStix®.
Seam Method Mannington Commercial Weld Rods or MCS-42

Chemical Seam Sealer with VST-96 Application Kit.
Mannington Seam Coater Pen for high traffic areas. Note:

Heat welding is the recommended procedure
for healthcare and high traffic applications.
Testing
HUD/FHA Meets / Exceeds
ADAG (American Disability Act Guidelines) Passes
Flexibility (ASTM F137) Passes - 1 1/2” Mandrel - No Crack/Break
Static Load (ASTM F970) Passes - Resid. Indent = 0.005”
Static Load (ASTM F970 mod.) Passes - 2,000 PSI; Resid. Indent = 0.005”
Rolling Resistance/Caster Chair (ISO 4918) 25,000 Cycles, No Significant Change
Short Term Residual Indentation (ASTM F1914/F1303) Passes - Must be < 0.007”
Flooring Radiant Panel (ASTM E648) Passes - Class 1; = 0.45 watts/cm2
Smoke Density (ASTM E662) Passes - = 450
Slip Resistance (ASTM C1028, Dry) Passes - = 0.5 Leather; 0.6 Rubber
Acoustic IIC (ASTM E492) 50 - 6” Concrete with Drop Ceiling
Acoustic STC (ASTM E90) 63 - 6” Concrete with Drop Ceiling
Resistance to Light (ASTM F1515) Passes - < 8 Delta E Color Change
Chemical Resistance (ASTM F925) Passes - No More Than Slight Change
Resistance to Heat (ASTM F1514) Passes - < 8 Delta E Color Change
Resistance to Mold/Mildew (ASTM G21/E2180) Passes - No More Than Slight Change
Environmental Data
Recycled Content Contains 5% post-consumer recycled content
Indoor Air Quality FloorScore Certified; CDPH v1.1-2010
Product Declarations EPD
LEED May contribute to LEED credits:
Building Product Disclosure & Optimization - EPDs
Building Product Disclosure & Optimization - Sourcing Raw Materials
Building Product Disclosure & Optimization - IEQc2 - Low Emitting Materials
mindful MATERIALS Visit mM Origin website, mindfulmaterials.

origin.build, for current transparency information
Manufacturing Salem, NJ (USA) - ISO 14001 EMS & ISO 9001 QMS Registered
Warranty
Limited 12-Year Commercial Warranty
Limited 12-Year Quantum Guard Elite® Wear Warranty
