PATCRAFT
CENTERLINE
All Patcraft running line flooring
products are priced by
" QUOTE REQUEST ONLY "
CenterlineProduct SpecificationsCollection Name InfrastructureStyle Number I0523Product Type BroadloomConstruction Multi-Level Pattern LoopFiber Type Eco Solution Q® NylonDye Method 100% solution dyed English MetricGauge 1/10 39.37 per 10 cmStitches Per Inch 11.0 43.31 per 10 cmTufted Pile Height 6/32" 4.76mmTufted Yarn Weight 18 oz 610.30 g/m²Finished Pile Thickness 0.071 1.80 mmTotal Thickness 0.244 6.20 mmProduct Size 12 foot 3.66 mAverage Density 9127 16.99 kilotexInstallation Pattern Repeat 12" W X 12" L 30.48 cm w x 30.48 cm lProtective Treatments SSP® Shaw Soil ProtectionPrimary Backing SyntheticSecondary Backing Ultraloc®Performance SpecificationsTraffic Class Severe (TARR)Antimicrobial Assessment Passes (AATCC-174)(When installed using Shaw 1036 adhesive)Methenamine Pill Test Passes (DOCFF-1-70)Radiant Panel Class I (ASTM E-648)NBS Smoke Less than 450 (ASTM-E-662)Electrostatic Propensity Less than 3.5 kV (AATCC-134)CRI Green Label Plus Certified GLP 8472ADA Compliance This product meets the guidelines as set forth in the Americans with Disabilities Act for minimum static coefficient of friction of 0.6 for accessible routes.Warranty InformationBroadloom Lifetime Commercial Limited WarrantyInstallation MethodsDirect Gluelue
Centerline
Product Specifications
Collection Name Infrastructure
Style Number I0523
Product Type Broadloom
Construction Multi-Level Pattern Loop
Fiber Type Eco Solution Q® Nylon
Dye Method 100% solution dyed
English Metric
Gauge 1/10 39.37 per 10 cm
Stitches Per Inch 11.0 43.31 per 10 cm
Tufted Pile Height 6/32" 4.76mm
Tufted Yarn Weight 18 oz 610.30 g/m²
Finished Pile Thickness 0.071 1.80 mm
Total Thickness 0.244 6.20 mm
Product Size 12 foot 3.66 m
Average Density 9127 16.99 kilotex
Installation Pattern Repeat 12" W X 12" L 30.48 cm w x 30.48 cm l
Protective Treatments SSP® Shaw Soil Protection
Primary Backing Synthetic
Secondary Backing Ultraloc®
Performance Specifications
Traffic Class Severe (TARR)
Antimicrobial Assessment Passes (AATCC-174)
(When installed using Shaw 1036 adhesive)
Methenamine Pill Test Passes (DOCFF-1-70)
Radiant Panel Class I (ASTM E-648)
NBS Smoke Less than 450 (ASTM-E-662)
Electrostatic Propensity Less than 3.5 kV (AATCC-134)
CRI Green Label Plus Certified GLP 8472
ADA Compliance This product meets the guidelines as set forth in the Americans with Disabilities Act for minimum static coefficient of friction of 0.6 for accessible routes.
Warranty Information
Broadloom Lifetime Commercial Limited Warranty
Installation Methods
Direct Gluelue
