INTERFACE
DRAWN LINES
All Interface products are
priced by bid basis only
Please email us with your job
requirements for a quote !!!
Product Specifications
Product Number A009
Product Construction High Performance Luxury Vinyl Tile
Class / ASTM F1700 Class III Printed Vinyl Tile
Wear Layer Thickness 22 mil
Total Thickness 4.5 mm
Backing Class Commercial Grade
Finish Ceramor
Nominal Dimensions 25cm x 1m (9.845 in x 39.38 in)
Performance Specifications
IIC Sound Rating (ASTM E492-09) 57 IIC
Slip Resistance (ASTM D2047) >0.55 wet/dry, ADA Compliant
Static Load Limit (ASTM F970) 1500 psi
Flexibility (ASTM F137) Passes
Resistance to Heat (ASTM F1514) Passes
Resistance to Light (ASTM F1515) Passes
Radiant Flux (ASTM E648) Class I
Smoke Density (ASTM E 662) ≤ 450
Size & Squareness (ASTM F2055) Passes, +/- 0.016 in. per linear foot
Thickness (ASTM F386) Passes
Dimensional Stability (ASTM F2199) Passes
Residual Indentation (ASTM F1914) Passes
Resistance to Chemicals (ASTM F925) Passes
Health + Environmental Specifications
Carbon Footprint 12.4 Kg CO2/M2
Carbon Offsets Carbon Neutral Floors™
Indoor Air Quality GREENGUARD Gold
FloorScore®
CDPH 01350 compliant
Material Composition Free of Ortho Phthalates, Added Formaldehyde and Heavy Metal Stabilizers
Disclosure of Environmental Impacts Environmental Product Declaration
Disclosure of Product Ingredients Health Product Declaration
Environmental Certifications NSF/ANSI 332 Silver
LEED v4 Contributes to IEQ: Low Emitting Materials; M&R: EPD and EPR
End of Life Fully Recyclable into Carpet Tile Backing through ReEntry®
Packaging
Quantity per Carton 26.91 sq. ft. (2.5 m²)
Pieces per Carton 10
Weight per Carton 18 kg (40 lbs)
Cartons per Pallet 40
Pallets per Truckload 20
Technical Information
Installation See Interface LVT Installation Guidelines online
Maintenance Recommended Interface LVT Maintenance Guidelines
Reclamation Recyclable through ReEntry® - Call 1.888.733.6873 (U.S.) / 1.866.398.3191 (Canada)
Warranty 15 Year Standard LVT Warranty
