Click Refresh PRODUCT SPECIFICATIONS
STYLE NAME CLICK REFRESH
STYLE NUMBER I600V
CONSTRUCTION LVT with In*Step™ Locking System
WEAR LAYER THICKNESS 20 mil
OVERALL THICKNESS 0.197 inches
REFERENCE SPECIFICATION Class III printed film vinyl plank
ASTM F 1700 Type B (embossed)
FINISH ExoGuard™
INSTALLATION Floating
RECOMMENDED ADHESIVE None required, Not recommended
Packaging
PLANK SIZE 7.28 in W x 47.10 in L
PIECES /BOX 8
SQ FT /BOX 19.27
WEIGHT (LB /BOX) 33.70
Performance Testing
STATIC LOAD / ASTM F 970 Modified – 1000 psi (lbs/sq in)
RESIDUAL INDENTATION / ASTM 1914 Passes <8%
RESISTANCE TO CHEMICALS / ASTM 925 Passes
RADIANT FLUX / ASTM E 648 Class I
SMOKE DENSITY / ASTM E 662 <450
IIC SOUND RATING / ASTM E 492 56 when tested over 6” concrete with ceiling plenum
Warranty
15 Year Limited Commercial Warranty
