PATCRAFT
FORMWORK
All Patcraft running line flooring
products are priced by
" QUOTE REQUEST ONLY "
FormworkProduct SpecificationsCollection Name InfrastructureStyle Number I0518Product Type ModularConstruction Mulit-Level Pattern LoopFiber Type Eco Solution Q® NylonDye Method 100% solution dyed English MetricGauge 1/10 39.37 per 10 cmStitches Per Inch 9.8 38.58 per 10 cmTufted Pile Height 6/32" 4.76mmTufted Yarn Weight 16.0 oz 542.49 g/m²Finished Pile Thickness 0.070 1.78 mmTotal Thickness 0.218 5.54 mmProduct Size 24" x 24" 60.96 cm x 60.96 cmAverage Density 8,229 15.32 kilotexSquare Yards per Box 5.33Installation Pattern Repeat noneProtective Treatments SSP® Shaw Soil ProtectionPrimary Backing SyntheticSecondary Backing EcoWorx® TileGSA Approved Product Yes GSA ApprovedPerformance SpecificationsTraffic Class Heavy (TARR)Antimicrobial Assessment Passes (AATCC-174)(When installed using Shaw 5036 adhesive)Methenamine Pill Test Passes (DOCFF-1-70)Radiant Panel Class I (ASTM E-648)NBS Smoke Less than 450 (ASTM-E-662)Electrostatic Propensity Less than 3.5 kV (AATCC-134)CRI Green Label Plus Certified GLP 9968ADA Compliance This product meets the guidelines as set forth in the Americans with Disabilities Act for minimum static coefficient of friction of 0.6 for accessible routes.Warranty InformationCarpet Tile Lifetime Commerical Limited Warranty
Formwork
Product Specifications
Collection Name Infrastructure
Style Number I0518
Product Type Modular
Construction Mulit-Level Pattern Loop
Fiber Type Eco Solution Q® Nylon
Dye Method 100% solution dyed
English Metric
Gauge 1/10 39.37 per 10 cm
Stitches Per Inch 9.8 38.58 per 10 cm
Tufted Pile Height 6/32" 4.76mm
Tufted Yarn Weight 16.0 oz 542.49 g/m²
Finished Pile Thickness 0.070 1.78 mm
Total Thickness 0.218 5.54 mm
Product Size 24" x 24" 60.96 cm x 60.96 cm
Average Density 8,229 15.32 kilotex
Square Yards per Box 5.33
Installation Pattern Repeat none
Protective Treatments SSP® Shaw Soil Protection
Primary Backing Synthetic
Secondary Backing EcoWorx® Tile
GSA Approved Product Yes GSA Approved
Performance Specifications
Traffic Class Heavy (TARR)
Antimicrobial Assessment Passes (AATCC-174)
(When installed using Shaw 5036 adhesive)
Methenamine Pill Test Passes (DOCFF-1-70)
Radiant Panel Class I (ASTM E-648)
NBS Smoke Less than 450 (ASTM-E-662)
Electrostatic Propensity Less than 3.5 kV (AATCC-134)
CRI Green Label Plus Certified GLP 9968
ADA Compliance This product meets the guidelines as set forth in the Americans with Disabilities Act for minimum static
coefficient of friction of 0.6 for accessible routes.
Warranty Information
Carpet Tile Lifetime Commerical Limited Warranty
