PATCRAFT
COLOR CHOICE MODULAR
All Patcraft running line flooring
products are priced by
" QUOTE REQUEST ONLY "
Color Choice ModularProduct SpecificationsCollection Name pdQStyle Number I0204Product Type ModularConstruction Level LoopFiber Type Eco Solution Q® SD NylonDye Method 100% Solution Dyed English MetricGauge 1/10 inch 39.4 per 10cmStitches Per Inch 11.5 per inch 45 per 10cmTufted Pile Height 5/32" 3.97mmTufted Yarn Weight 30.0 oz/yd2 1017.2 gms/sqmFinished Pile Thickness 0.093 inches 2.36 mmTotal Thickness 0.263 inches 6.68 mmProduct Size 24.0 X 24.0 inches 61.0 x 61.0 cmAverage Density 11613 per cu.yd. 16.04Installation Pattern Repeat NoneProtective Treatments SSP® Shaw Soil ProtectionPrimary Backing Non-Woven SyntheticSecondary Backing EcoWorx® TileGSA Approved Product Yes GSA ApprovedPerformance SpecificationsTraffic Class Severe (TARR)Antimicrobial Assessment Passes (AATCC-174)(When installed using Shaw 5036 adhesive)Methenamine Pill Test Passes (DOCFF-1-70)Radiant Panel Class I (ASTM E-648)NBS Smoke Less than 450 (ASTM-E-662)Electrostatic Propensity Less than 3.5 kV (AATCC-134)CRI Green Label Plus GLP9968ADA Compliance This product meets the guidelines as set forth in the Americans with Disabilities Act for minimum static coefficient of friction of 0.6 for accessible routes.Warranty InformationLifetime Commercial Limited
Color Choice Modular
Product Specifications
Collection Name pdQ
Style Number I0204
Product Type Modular
Construction Level Loop
Fiber Type Eco Solution Q® SD Nylon
Dye Method 100% Solution Dyed
English Metric
Gauge 1/10 inch 39.4 per 10cm
Stitches Per Inch 11.5 per inch 45 per 10cm
Tufted Pile Height 5/32" 3.97mm
Tufted Yarn Weight 30.0 oz/yd2 1017.2 gms/sqm
Finished Pile Thickness 0.093 inches 2.36 mm
Total Thickness 0.263 inches 6.68 mm
Product Size 24.0 X 24.0 inches 61.0 x 61.0 cm
Average Density 11613 per cu.yd. 16.04
Installation Pattern Repeat None
Protective Treatments SSP® Shaw Soil Protection
Primary Backing Non-Woven Synthetic
Secondary Backing EcoWorx® Tile
GSA Approved Product Yes GSA Approved
Performance Specifications
Traffic Class Severe (TARR)
Antimicrobial Assessment Passes (AATCC-174)
(When installed using Shaw 5036 adhesive)
Methenamine Pill Test Passes (DOCFF-1-70)
Radiant Panel Class I (ASTM E-648)
NBS Smoke Less than 450 (ASTM-E-662)
Electrostatic Propensity Less than 3.5 kV (AATCC-134)
CRI Green Label Plus GLP9968
ADA Compliance This product meets the guidelines as set forth in the Americans with Disabilities Act for minimum static coefficient of friction of 0.6 for accessible routes.
Warranty Information
Lifetime Commercial Limited
